📐 Architectural Blueprints • Exact Footprint, Clearance & Dedicated Circuit Specs
Top-Down Trailer Floorplans & Site Placement Checklist
Share these exact dimensions with your wedding planner, tent rental crew, estate caretaker, or jobsite superintendent to verify gate width, stair deployment footprint, and dedicated 120V/20A electrical circuits.
⚠️ Mandatory Site Electrical Rule (Dedicated 120V/20A Circuit):
Never share a restroom trailer's 120V/20A circuit with DJ subwoofers, catering warming ovens, espresso machines, or tent chandeliers. Rooftop AC + hot-water handwash heaters draw 14–18 continuous amps; if dedicated shore power is further than 100 ft away, select a <58 dB Whisper-Quiet Inverter Generator.
Max 100ft 10-Gauge Cord
Up to 125 Guests
12' Box • 16' w/ Hitch
2-Stall Boutique Suite (1W / 1M)
- • Footprint: 12' Box (16' w/ tongue) × 11' Wide (stairs deployed)
- • Clearance: 10'6" Height (12' tree branch clearance)
- • Utilities: (1) 120V/20A • 100g Fresh / 200g Waste (~750 flushes)
$1,250 – $1,850 / wknd
101–175 Guests
16'–18' Box • 22' Total
3–4 Stall Executive Suite (2W / 2M)
- • Footprint: 16'–18' Box (22' w/ tongue) × 11.5' Wide (stairs out)
- • Turning & Gate: 12' straight gate width; 45' delivery turning radius
- • Utilities: (2) 120V/20A • 150g Fresh / 300g Waste (~1,050 flushes)
$1,550 – $2,650 / wknd
★ Ideal 175–275 Guests
20'–22' Box • 26' Total
5 to 6-Stall Luxury Hospitality Suite (3W / 3M)
- • Footprint: 20'–22' Box (26' w/ tongue) × 11.5' Wide (stairs out)
- • Layout: 3 Women's Stalls + 1 Men's Stall & 2 Urinals + Dual Vanities
- • Utilities: (2) 120V/20A • 175g Fresh / 375g Waste (~1,300 flushes)
$2,150 – $3,350 / wknd
275–500+ VIP Guests
24'–28' Box • 32' Total
8 to 10-Stall Presidential Suite (Dual Flow)
- • Footprint: 24'–28' Box (32' w/ tongue) × 12' Wide (stairs out)
- • Placement: Compacted gravel/paved pad; 50' straight approach
- • Utilities: (2) 20A/30A • 200g Fresh / 450g+ Waste (~1,500 flushes)
$2,900 – $5,200 / wknd
